Energy Storage Solution
Battery VES Series
VES 200k-430kWh-1F
- Price: 0 THB
quantity
Order within 72 hrs
product infomation
Dynamic Commercial Battery Energy Storage for Every Need Elevate Your Business with VES 200k-430kWh-1F The VES 200k-430kWh-1F, a standout in our VES Series, epitomizes commercial battery energy storage innovation. Housed in a 10ft container, this all-in-one modular system offers 200kW/430kWh of power, adept for both on-grid and off-grid settings. Tailor-made for businesses aiming to optimize energy usage, it's your gateway to operational excellence, supporting a wide range of applications from peak shaving and load shifting to ensuring uninterrupted power supply in critical infrastructures.Delivery option
- fast shipping
- 5 Year Warranty
share
Applications Highlight:
The VES 200k-430kWh-1F, a standout in our VES Series, epitomizes commercial battery energy storage innovation. Housed in a 10ft container, this all-in-one modular system offers 200kW/430kWh of power, adept for both on-grid and off-grid settings. Tailor-made for businesses aiming to optimize energy usage, it's your gateway to operational excellence, supporting a wide range of applications from peak shaving and load shifting to ensuring uninterrupted power supply in critical infrastructures.
- Operational Efficiency: Ideal for factories and commercial buildings, reducing energy bills through intelligent peak shaving.
- Critical Infrastructure Resilience: Keeps hospitals and schools running smoothly, safeguarding essential services.
- Green Energy Initiatives: Supports solar carport and EV charging projects, propelling your sustainability agenda.
- Adaptable and Scalable: : Modular design fits seamlessly into existing setups, offering expandability as your energy needs grow.
| Model | VESS Plus-200k |
|---|---|
| AC Parameters | |
| Nominal Power | 200KW |
| AC Input/Output Voltage | 400V |
| AC Frequency | 50Hz/60Hz |
| Grid Type | 3W+N+PE / 3W+PE |
| Max. Efficiency | 97.3% (Peak) |
| Max. Load capacity | 110% (Continoues), 120(1 min) |
| PV Parameters | |
| Input Power | 200kW |
| MPPT Voltage Range | 200-650V (320-650V with Full load) |
| Max. Input Current | 640A |
| Battery Parameters | |
| Nominal Energy | 430kWh |
| VE64280 Battery Module Electrical Spec. | 64V/280AH/17.92kWh |
| VE64280 Battery Module Physical Spec. | 440*912*265mm (W*H*D)/132kg |
| Number of Battery Modules | 24 |
| Nominal Battery Voltage | 768V |
| Max.Charge/discharge Current | 280A/280A |
| Battery Certification | IEC62619, EN61000-6-2,4, UN38.3 |
| General Specification | |
| Thermal Management | Fan/Heat exchanger/Air conditioner |
| Noise | <70dB |
| IP Rating | IP54 |
| Operation Temp Range. | -20°C~60°C |
| Operation Ralative Humidity | 0°C~95'C (No condensation) |
| Altitude | <2000m |
| Weight | Approx.5600kg |
| Dimension | 3700*1200*H2300 (W*D*H)mm |
| Accessories | Smoke sensor, door sensor, water sensor,fire fighting.EPO |
| On/Off Grid Switch Time | 30ms |
| Communication | RS485/CAN/Lan/Dry contact |
| Galvanic isolation | Transformer (optional) |
| System Certificates | IEC63056, IEC62477-1, IEC62109-1/2, GB/T36276 |
